Periodic Trends: Ionization Energy

Learning Objectives

  • Define ionization energy.
  • Describe factors affecting ionization energy.
  • Describe how ionization energy changes across a period.
  • Describe how ionization energy changes down a group.


Why do sheep travel in herds?

Sheep herds are like protons and electronsLike many other animals, sheep travel in herds.  The tendency is for each individual sheep to stay with the herd. However, a sheep may sometimes wander off, depending on how strong the attraction is for a particular food or water supply.  At other times, a sheep may become frightened and run off.  Whether a sheep chooses to stay with the herd or go its own way depends on the balance between attraction to the herd and attraction to the outside influence.

There is an on-going tension between the electrons and protons in an atom.  Reactivity of the atom depends in part on how easily the electrons can be removed from the atom.  We can measure this quantity and use it to make predictions about the behaviors of atoms.

Ionization energy is the energy required to remove an electron from a specific atom. It is measured in kJ/mol, which is an energy unit, much like calories. The ionization energies associated with some elements are described in the Table 1. For any given atom, the outermost valence electrons will have lower ionization energies than the inner-shell kernel electrons. As more electrons are added to a nucleus, the outer electrons become shielded from the nucleus by the inner shell electrons. This is called electron shielding .

Table 1. Ionization Energies (kJ/mol) of the First 18 Elements

Element

IE 1

IE 2

IE 3

IE 4

IE 5

IE 6

H

1312

He

2373

5251

Li

520

7300

11,815

Be

899

1757

14,850

21,005

B

801

2430

3660

25,000

32,820

C

1086

2350

4620

6220

38,000

47,261

N

1400

2860

4580

7500

9400

53,000

O

1314

3390

5300

7470

11,000

13,000

If we plot the first ionization energies vs. atomic number for the main group elements, we would have the following trend

Graph of ionization energy versus atomic number Figure 1. Ionization energy and atomic number.


Moving from left to right across the periodic table, the ionization energy for an atom increases.  We can explain this by considering the nuclear charge of the atom.  The more protons in the nucleus, the stronger the attraction of the nucleus to electrons.  This stronger attraction makes it more difficult to remove electrons.

Within a group, the ionization energy decreases as the size of the atom gets larger.  On the graph, we see that the ionization energy increases as we go up the group to smaller atoms.  In this situation, the first electron removed is farther from the nucleus as the atomic number (number of protons) increases.  Being farther away from the positive attraction makes it easier for that electron to be pulled off.

Trends of ionization energy, electron affinity, and metallic character

Summary

  • Ionization energy refers to the amount of energy needed to remove an electron from an atom.
  • Ionization energy decreases as we go down a group.
  • Ionization energy increases from left to right across the periodic table.


Practice

Use the following link to answer the questions below:

http://dl.clackamas.cc.or.us/ch104-07/ionization_energy.htm

  1. What is a “gaseous atom?”
  2. Why would the ionization energy for O be somewhat less than that for N?
  3. Why is a third-level electron easier to remove than a first-level one?


Review

  1. Define “ionization energy.”
  2. Do valence electrons have larger or smaller ionization energies that the inner-shell kernel electrons?
  3. What is electron shielding?
  4. Describe the trends in ionization energy from left to right across the periodic table.
  5. Describe the trends in ionization energy from top to bottom of a group in the periodic table.
  6. Why is the second ionization energy for lithium so much larger than the first ionization energy?


Glossary

  • electron shielding: As more electrons are added to a nucleus, the outer electrons become shielded from the nucleus by the inner shell electrons
  • ionization energy: The energy required to remove an electron from a specific atom. It is measured in kJ/mol, which is an energy unit, much like calories.
