- Identify the most common bacteria that can cause infections of the upper and lower respiratory tract
- Compare the major characteristics of specific bacterial diseases of the respiratory tract
The respiratory tract can be infected by a variety of bacteria, both gram positive and gram negative. Although the diseases that they cause may range from mild to severe, in most cases, the microbes remain localized within the respiratory system. Fortunately, most of these infections also respond well to antibiotic therapy.
Figure 1. This scanning electron micrograph of Streptococcus pyogenes
shows the characteristic cellular phenotype resembling chains of cocci. (credit: modification of work by U.S. Centers for Disease Control and Prevention - Medical Illustrator)
A common upper respiratory infection, streptococcal pharyngitis
) is caused by Streptococcus pyogenes
. This gram-positive bacterium appears as chains of cocci, as seen in Figure 1. Rebecca Lancefield
serologically classified streptococci in the 1930s using carbohydrate antigens from the bacterial cell walls. S. pyogenes
is the sole member of the Lancefield group A streptococci and is often referred to as GAS, or group A strep.
Similar to streptococcal infections of the skin, the mucosal membranes of the pharynx are damaged by the release of a variety of exoenzymes and exotoxins by this extracellular pathogen. Many strains of S. pyogenes
can degrade connective tissues by using hyaluronidase
. Streptokinase activates plasmin, which leads to degradation of fibrin and, in turn, dissolution of blood clots, which assists in the spread of the pathogen. Released toxins include streptolysin
s that can destroy red and white blood cells. The classic signs of streptococcal pharyngitis are a fever higher than 38 °C (100.4 °F); intense pharyngeal pain; erythema associated with pharyngeal inflammation; and swollen, dark-red palatine tonsils, often dotted with patches of pus; and petechiae (microcapillary hemorrhages) on the soft or hard palate (roof of the mouth) (Figure 2). The submandibular lymph nodes beneath the angle of the jaw are also often swollen during strep throat.
Some strains of group A streptococci
produce erythrogenic toxin
. This exotoxin is encoded by a temperate bacteriophage (bacterial virus) and is an example of phage conversion
(see The Viral Life Cycle
). The toxin attacks the plasma membranes of capillary endothelial cells and leads to scarlet fever
(or scarlatina), a disseminated fine red rash on the skin, and strawberry tongue
, a red rash on the tongue (Figure 2). Severe cases may even lead to streptococcal toxic shock syndrome (STSS)
, which results from massive superantigen production that leads to septic shock and death.
can be easily spread by direct contact or droplet transmission through coughing and sneezing. The disease can be diagnosed quickly using a rapid enzyme immunoassay for the group A antigen. However, due to a significant rate of false-negative results (up to 30%), culture identification is still the gold standard to confirm pharyngitis due to S. pyogenes
. S. pyogenes
can be identified as a catalase-negative, beta hemolytic bacterium that is susceptible to 0.04 units of bacitracin. Antibiotic resistance is limited for this bacterium, so most β
-lactams remain effective; oral amoxicillin and intramuscular penicillin G are those most commonly prescribed.
Figure 2. Streptococcal infections of the respiratory tract may cause localized pharyngitis or systemic signs and symptoms. (a) The characteristic appearance of strep throat: bright red arches of inflammation with the presence of dark-red spots (petechiae). (b) Scarlet fever presents as a rash on the skin. (credit a: modification of work by Centers for Disease Control and Prevention; credit b: modification of work by Alicia Williams)
Sequelae of S. pyogenes Infections
One reason strep throat infections are aggressively treated with antibiotics is because they can lead to serious sequelae
, later clinical consequences of a primary infection. It is estimated that 1%–3% of untreated S. pyogenes
infections can be followed by nonsuppurative (without the production of pus) sequelae that develop 1–3 weeks after the acute infection has resolved. Two such sequelae are acute rheumatic fever
and acute glomerulonephritis
Acute rheumatic fever can follow pharyngitis caused by specific rheumatogenic strains of S. pyogenes
(strains 1, 3, 5, 6, and 18). Although the exact mechanism responsible for this sequela remains unclear, molecular mimicry between the M protein of rheumatogenic strains of S. pyogenes
and heart tissue is thought to initiate the autoimmune attack. The most serious and lethal clinical manifestation of rheumatic fever is damage to and inflammation of the heart (carditis
). Acute glomerulonephritis also results from an immune response to streptococcal antigens following pharyngitis and cutaneous infections. Acute glomerulonephritis develops within 6–10 days after pharyngitis, but can take up to 21 days after a cutaneous infection. Similar to acute rheumatic fever, there are strong associations between specific nephritogenic strains of S. pyogenes
and acute glomerulonephritis, and evidence suggests a role for antigen mimicry and autoimmunity. However, the primary mechanism of acute glomerulonephritis appears to be the formation of immune complexes between S. pyogenes
antigens and antibodies, and their deposition between endothelial cells of the glomeruli of kidney. Inflammatory response against the immune complexes leads to damage and inflammation of the glomeruli (glomerulonephritis).
Think about It
- What are the symptoms of strep throat?
- What is erythrogenic toxin and what effect does it have?
- What are the causes of rheumatic fever and acute glomerulonephritis?
Acute Otitis Media
An infection of the middle ear
is called acute otitis media
), but often it is simply referred to as an earache. The condition is most common between ages 3 months and 3 years. In the United States, AOM is the second-leading cause of visits to pediatricians by children younger than age 5 years, and it is the leading indication for antibiotic prescription.
AOM is characterized by the formation and accumulation of pus in the middle ear. Unable to drain, the pus builds up, resulting in moderate to severe bulging of the tympanic membrane and otalgia (ear pain). Inflammation resulting from the infection leads to swelling of the eustachian tubes, and may also lead to fever, nausea, vomiting, and diarrhea, particularly in infants. Infants and toddlers who cannot yet speak may exhibit nonverbal signs suggesting AOM, such as holding, tugging, or rubbing of the ear, as well as uncharacteristic crying or distress in response to the pain.
AOM can be caused by a variety of bacteria. Among neonates, S. pneumoniae
is the most common cause of AOM, but Escherichia coli
spp., and group B Streptococcus
species can also be involved. In older infants and children younger than 14 years old, the most common bacterial causes are S. pneumoniae
, Haemophilus influenzae
, or Moraxella catarrhalis
. Among S. pneumoniae
encapsulated strains are frequent causes of AOM. By contrast, the strains of H. influenzae
and M. cattarhalis
that are responsible for AOM do not possess a capsule. Rather than direct tissue damage by these pathogens, bacterial components such as lipopolysaccharide (LPS) in gram-negative pathogens induce an inflammatory response that causes swelling, pus, and tissue damage within the middle ear (Figure 3).
Figure 3. (a) A healthy tympanic membrane; the middle ear bones can be seen behind the membrane. (b) An ear with chronic inflammation that has resulted in a torn membrane, erosion of the inner ear bones, and mucus buildup. (credit a: modification of work by “DrER.tv”/YouTube; credit b: modification of work by Li Mg, Hotez PJ, Vrabec JT, Donovan DT)
Any blockage of the eustachian tubes, with or without infection, can cause fluid to become trapped and accumulate in the middle ear. This is referred to as otitis media with effusion (OME)
. The accumulated fluid offers an excellent reservoir for microbial growth and, consequently, secondary bacterial infections often ensue. This can lead to recurring and chronic earaches, which are especially common in young children. The higher incidence in children can be attributed to many factors. Children have more upper respiratory infections, in general, and their eustachian tubes are also shorter and drain at a shallower angle. Young children also tend to spend more time lying down than adults, which facilitates drainage from the nasopharynx through the eustachian tube and into the middle ear. Bottle feeding while lying down enhances this risk because the sucking action on the bottle causes negative pressure to build up within the eustachian tube, promoting the movement of fluid and bacteria from the nasopharynx.
Diagnosis is typically made based on clinical signs and symptoms, without laboratory testing to determine the specific causative agent. Antibiotics are frequently prescribed for the treatment of AOM. High-dose amoxicillin
is the first-line drug, but with increasing resistance concerns, macrolides and cephalosporin
s may also be used. The pneumococcal conjugate vaccine (PCV13) contains serotypes that are important causes of AOM, and vaccination has been shown to decrease the incidence of AOM. Vaccination against influenza has also been shown to decrease the risk for AOM, likely because viral infections like influenza predispose patients to secondary infections with S. pneumoniae
. Although there is a conjugate vaccine available for the invasive serotype B of H. influenzae
, this vaccine does not impact the incidence of H. influenzae
AOM. Because unencapsulated strains of H. influenzae
and M. catarrhalis
are involved in AOM, vaccines against bacterial cellular factors other than capsules will need to be developed.
The microbial community of the nasopharynx is extremely diverse and harbors many opportunistic pathogens, so it is perhaps not surprising that infections leading to rhinitis
have many possible causes. These conditions often occur as secondary infections after a viral infection, which effectively compromises the immune defenses and allows the opportunistic bacteria to establish themselves. Bacterial sinusitis involves infection and inflammation within the paranasal sinuses. Because bacterial sinusitis rarely occurs without rhinitis, the preferred term is rhinosinusitis
. The most common causes of bacterial rhinosinusitis are similar to those for AOM, including S. pneumoniae
, H. influenzae
, and M. catarrhalis
Think about It
- What are the usual causative agents of acute otitis media?
- What factors facilitate acute otitis media with effusion in young children?
- What factor often triggers bacterial rhinosinusitis?
Figure 4. The pseudomembrane in a patient with diphtheria presents as a leathery gray patch consisting of dead cells, pus, fibrin, red blood cells, and infectious microbes. (credit: modification of work by Putnong N, Agustin G, Pasubillo M, Miyagi K, Dimaano EM)
The causative agent of diphtheria
, Corynebacterium diphtheriae
, is a club-shaped, gram-positive rod that belongs to the phylum Actinobacteria
. Diphtheroids are common members of the normal nasopharyngeal microbiota. However, some strains of C. diphtheriae
become pathogenic because of the presence of a temperate bacteriophage-encoded protein—the diphtheria toxin
. Diphtheria is typically a respiratory infection of the oropharynx but can also cause impetigo-like lesions on the skin. Although the disease can affect people of all ages, it tends to be most severe in those younger than 5 years or older than 40 years. Like strep throat, diphtheria is commonly transmitted in the droplets and aerosols produced by coughing. After colonizing the throat, the bacterium remains in the oral cavity and begins producing the diphtheria toxin. This protein is an A-B toxin
that blocks host-cell protein synthesis by inactivating elongation factor (EF)-2 (see Virulence Factors of Bacterial and Viral Pathogens
). The toxin’s action leads to the death of the host cells and an inflammatory response. An accumulation of grayish exudate consisting of dead host cells, pus, red blood cells, fibrin, and infectious bacteria results in the formation of a pseudomembrane
. The pseudomembrane can cover mucous membranes of the nasal cavity, tonsils, pharynx, and larynx (Figure 4). This is a classic sign of diphtheria. As the disease progresses, the pseudomembrane can enlarge to obstruct the fauces of the pharynx or trachea and can lead to suffocation and death. Sometimes, intubation
, the placement of a breathing tube in the trachea, is required in advanced infections. If the diphtheria toxin spreads throughout the body, it can damage other tissues as well. This can include myocarditis (heart damage) and nerve damage that may impair breathing.
The presumptive diagnosis of diphtheria is primarily based on the clinical symptoms (i.e., the pseudomembrane) and vaccination history, and is typically confirmed by identifying bacterial cultures obtained from throat swabs. The diphtheria toxin itself can be directly detected in vitro using polymerase chain reaction (PCR)-based, direct detection systems for the diphtheria tox
gene, and immunological techniques like radial immunodiffusion or Elek’s immunodiffusion test.
Broad-spectrum antibiotics like penicillin and erythromycin tend to effectively control C. diphtheriae
infections. Regrettably, they have no effect against preformed toxins. If toxin production has already occurred in the patient, antitoxins (preformed antibodies against the toxin) are administered. Although this is effective in neutralizing the toxin, the antitoxins may lead to serum sickness
because they are produced in horses (see Hypersensitivities
Widespread vaccination efforts have reduced the occurrence of diphtheria worldwide. There are currently four combination toxoid vaccines available that provide protection against diphtheria and other diseases: DTaP, Tdap, DT, and Td. In all cases, the letters "d," "t," and "p" stand for diphtheria, tetanus, and pertussis, respectively; the "a" stands for acellular. If capitalized, the letters indicate a full-strength dose; lowercase letters indicate reduced dosages. According to current recommendations, children should receive five doses of the DTaP vaccine in their youth and a Td booster every 10 years. Children with adverse reactions to the pertussis vaccine may be given the DT vaccine in place of the DTaP.
Think about It
- What effect does diphtheria toxin have?
- What is the pseudomembrane composed of?
Pneumonia is a general term for infections of the lungs that lead to inflammation and accumulation of fluids and white blood cells in the alveoli. Pneumonia can be caused by bacteria, viruses, fungi, and other organisms, although the vast majority of pneumonias are bacterial in origin. Bacterial pneumonia is a prevalent, potentially serious infection; it caused more 50,000 deaths in the United States in 2014. As the alveoli fill with fluids and white blood cells (consolidation), air exchange becomes impaired and patients experience respiratory distress (Figure 5). In addition, pneumonia can lead to pleurisy
, an infection of the pleural membrane surrounding the lungs, which can make breathing very painful. Although many different bacteria can cause pneumonia under the right circumstances, three bacterial species cause most clinical cases: Streptococcus pneumoniae
, H. influenzae
, and Mycoplasma pneumoniae
. In addition to these, we will also examine some of the less common causes of pneumonia.
Figure 5. A chest radiograph of a patient with pneumonia shows the consolidations (lesions) present as opaque patches. (credit: modification of work by Centers for Disease Control and Prevention)
The most common cause of community-acquired bacterial pneumonia is Streptococcus pneumoniae
. This gram-positive, alpha hemolytic streptococcus is commonly found as part of the normal microbiota of the human respiratory tract. The cells tend to be somewhat lancet-shaped and typically appear as pairs (Figure 6). The pneumococci initially colonize the bronchioles of the lungs. Eventually, the infection spreads to the alveoli, where the microbe’s polysaccharide capsule interferes with phagocytic clearance. Other virulence factors include autolysin
s like Lyt A, which degrade the microbial cell wall, resulting in cell lysis and the release of cytoplasmic virulence factors. One of these factors, pneumolysin O
, is important in disease progression; this pore-forming protein damages host cells, promotes bacterial adherence, and enhances pro-inflammatory cytokine production. The resulting inflammatory response causes the alveoli to fill with exudate rich in neutrophils and red blood cells. As a consequence, infected individuals develop a productive cough with bloody sputum.
Figure 6. (a) This micrograph of Streptococcus pneumoniae
grown from a blood culture shows the characteristic lancet-shaped diplococcal morphology. (b) A colorized scanning electron micrograph of S. pneumoniae
. (credit a: modification of work by Centers for Disease Control and Prevention; credit b: modification of work by Janice Carr, Centers for Disease Control and Prevention)
Pneumococci can be presumptively identified by their distinctive gram-positive, lancet-shaped cell morphology and diplococcal arrangement. In blood agar cultures, the organism demonstrates alpha hemolytic colonies that are autolytic after 24 to 48 hours. In addition, S. pneumoniae
is extremely sensitive to optochin and colonies are rapidly destroyed by the addition of 10% solution of sodium deoxycholate. All clinical pneumococcal isolates are serotyped using the quellung reaction
with typing antisera produced by the CDC. Positive quellung reactions are considered definitive identification of pneumococci.
Antibiotics remain the mainstay treatment for pneumococci. β
-Lactams like penicillin
are the first-line drugs, but resistance to β
-lactams is a growing problem. When β
-lactam resistance is a concern, macrolides
may be prescribed. However, S. pneumoniae
resistance to macrolides and fluoroquinolones is increasing as well, limiting the therapeutic options for some infections. There are currently two pneumococcal vaccines available: pneumococcal conjugate vaccine
(PCV13) and pneumococcal polysaccharide vaccine
(PPSV23). These are generally given to the most vulnerable populations of individuals: children younger than 2 years and adults older than 65 years.
Figure 7. Culture of Haemophilus influenzae on a chocolate agar plate. (credit: modification of work by Centers for Disease Control and Prevention)
Encapsulated strains of Haemophilus influenzae
are known for causing meningitis, but nonencapsulated strains are important causes of pneumonia. This small, gram-negative coccobacillus is found in the pharynx of the majority of healthy children; however, Haemophilus
pneumonia is primarily seen in the elderly. Like other pathogens that cause pneumonia, H. influenzae
is spread by droplets and aerosols produced by coughing. A fastidious organism, H. influenzae
will only grow on media with available factor X (hemin) and factor V (NAD), like chocolate agar
(Figure 7). Serotyping must be performed to confirm identity of H. influenzae
Infections of the alveoli by H. influenzae
result in inflammation and accumulation of fluids. Increasing resistance to β-lactams
, and tetracyclines
presents challenges for the treatment of Haemophilus
pneumonia. Resistance to the fluoroquinolones
is rare among isolates of H. influenzae
but has been observed. As discussed for AOM, a vaccine directed against nonencapsulated H. influenzae,
if developed, would provide protection against pneumonia caused by this pathogen.
Elizabeth is a 6-year old who developed a serious cough that would not seem to go away. After 2 weeks, her parents became concerned and took her to the pediatrician, who suspected a case of bacterial pneumonia. Tests confirmed that the cause was Haemophilus influenzae. Fortunately, Elizabeth responded well to antibiotic treatment and eventually made a full recovery.
Because there had been several other cases of bacterial pneumonia at Elizabeth’s elementary school, local health officials urged parents to have their children screened. Of the children who were screened, it was discovered that greater than 50% carried H. influenzae in their nasal cavities, yet all but two of them were asymptomatic.
Why is it that some individuals become seriously ill from bacterial infections that seem to have little or no effect on others? The pathogenicity of an organism—its ability to cause host damage—is not solely a property of the microorganism. Rather, it is the product of a complex relationship between the microbe’s virulence factors and the immune defenses of the individual. Preexisting conditions and environmental factors such as exposure to secondhand smoke can make some individuals more susceptible to infection by producing conditions favorable to microbial growth or compromising the immune system. In addition, individuals may have genetically determined immune factors that protect them—or not—from particular strains of pathogens. The interactions between these host factors and the pathogenicity factors produced by the microorganism ultimately determine the outcome of the infection. A clearer understanding of these interactions may allow for better identification of at-risk individuals and prophylactic interventions in the future.
Mycoplasma Pneumonia (Walking Pneumonia)
Figure 8. A micrograph showing a small oval cell binding to a much larger cell.
Primary atypical pneumonia is caused by Mycoplasma pneumoniae
. This bacterium is not part of the respiratory tract’s normal microbiota and can cause epidemic disease outbreaks. Also known as walking pneumonia, mycoplasma pneumonia
infections are common in crowded environments like college campuses and military bases. It is spread by aerosols formed when coughing or sneezing. The disease is often mild, with a low fever and persistent cough. These bacteria, which do not have cell walls, use a specialized attachment organelle to bind to ciliated cells. In the process, epithelial cells are damaged and the proper function of the cilia is hindered (Figure 8).
Mycoplasma grow very slowly when cultured. Therefore, penicillin
and thallium acetate
are added to agar to prevent the overgrowth by faster-growing potential contaminants. Since M. pneumoniae
does not have a cell wall, it is resistant to these substances. Without a cell wall, the microbial cells appear pleomorphic. M. pneumoniae
infections tend to be self-limiting but may also respond well to macrolide antibiotic therapy. β
-lactams, which target cell wall synthesis, are not indicated for treatment of infections with this pathogen.
Chlamydial Pneumonias and Psittacosis
Chlamydial pneumonia can be caused by three different species of bacteria: Chlamydophila pneumoniae
(formerly known as Chlamydia pneumoniae
), Chlamydophila psittaci
(formerly known as Chlamydia psittaci
), and Chlamydia trachomatis
. All three are obligate intracellular pathogens and cause mild to severe pneumonia and bronchitis. Of the three, Chlamydophila pneumoniae
is the most common and is transmitted via respiratory droplets or aerosols. C. psittaci
, a zoonotic disease that primarily affects domesticated birds such as parakeets, turkeys, and ducks, but can be transmitted from birds to humans. Psittacosis is a relatively rare infection and is typically found in people who work with birds. Chlamydia trachomatis,
the causative agent of the sexually transmitted disease chlamydia, can cause pneumonia in infants when the infection is passed from mother to baby during birth.
Diagnosis of chlamydia by culturing tends to be difficult and slow. Because they are intracellular pathogens, they require multiple passages through tissue culture. Recently, a variety of PCR- and serologically based tests have been developed to enable easier identification of these pathogens. Tetracycline and macrolide antibiotics are typically prescribed for treatment.
Health Care-Associated Pneumonia
A variety of opportunistic bacteria that do not typically cause respiratory disease in healthy individuals are common causes of health care-associated pneumonia. These include Klebsiella pneumoniae
, Staphylococcus aureus
, and proteobacteria such as species of Escherichia
, and Serratia
. Patients at risk include the elderly, those who have other preexisting lung conditions, and those who are immunocompromised. In addition, patients receiving supportive therapies such as intubation, antibiotics, and immunomodulatory drugs may also be at risk because these interventions disrupt the mucociliary escalator and other pulmonary defenses. Invasive medical devices such as catheters, medical implants, and ventilators can also introduce opportunistic pneumonia-causing pathogens into the body.
Pneumonia caused by K. pneumoniae
is characterized by lung necrosis and "currant jelly sputum," so named because it consists of clumps of blood, mucus, and debris from the thick polysaccharide capsule produced by the bacterium. K. pneumoniae
is often multidrug resistant. Aminoglycoside and cephalosporin are often prescribed but are not always effective. Klebsiella
pneumonia is frequently fatal even when treated.
is another opportunistic pathogen that can cause serious cases of bacterial pneumonia in patients with cystic fibrosis
(CF) and hospitalized patients assisted with artificial ventilators. This bacterium is extremely antibiotic resistant and can produce a variety of exotoxins. Ventilator-associated pneumonia with P. aeruginosa
is caused by contaminated equipment that causes the pathogen to be aspirated into the lungs. In patients with CF, a genetic defect in the cystic fibrosis transmembrane receptor (CFTR) leads to the accumulation of excess dried mucus in the lungs. This decreases the effectiveness of the defensins
and inhibits the mucociliary escalator
. P. aeruginosa
is known to infect more than half of all patients with CF. It adapts to the conditions in the patient’s lungs and begins to produce alginate, a viscous exopolysaccharide that inhibits the mucociliary escalator. Lung damage from the chronic inflammatory response that ensues is the leading cause of mortality in patients with CF.
Think about It
- What three pathogens are responsible for the most prevalent types of bacterial pneumonia?
- Which cause of pneumonia is most likely to affect young people?
- In what contexts does Pseudomonas aeruginosa cause pneumonia?
Clinical Focus: Romelu, Part 2
This example continues Romelu’s story that started in Anatomy and Normal Microbiota of the Respiratory Tract
Romelu’s chest radiograph revealed an extensive consolidation in the right lung, and his sputum cultures revealed the presence of a gram-negative rod. His physician prescribed a course of the antibiotic clarithromycin. He also ordered the rapid influenza diagnostic tests (RIDTs) for type A and B influenza to rule out a possible underlying viral infection. Despite antibiotic therapy, Romelu’s condition continued to deteriorate, so he was admitted to the hospital.
- What are some possible causes of pneumonia that would not have responded to the prescribed antibiotic?
We’ll return to Romelu’s example in later pages.
Tuberculosis (TB) is one of the deadliest infectious diseases in human history. Although tuberculosis
infection rates in the United States are extremely low, the CDC estimates that about one-third of the world’s population is infected with Mycobacterium tuberculosis
, the causal organism of TB, with 9.6 million new TB cases and 1.5 million deaths worldwide in 2014.
is an acid-fast, high G + C, gram-positive, nonspore-forming rod. Its cell wall is rich in waxy mycolic acids, which make the cells impervious to polar molecules. It also causes these organisms to grow slowly. M. tuberculosis
causes a chronic granulomatous disease that can infect any area of the body, although it is typically associated with the lungs. M. tuberculosis
is spread by inhalation of respiratory droplets or aerosols from an infected person. The infectious dose of M. tuberculosis
is only 10 cells.
After inhalation, the bacteria enter the alveoli (Figure 9). The cells are phagocytized by macrophages but can survive and multiply within these phagocytes because of the protection by the waxy mycolic acid in their cell walls. If not eliminated by macrophages, the infection can progress, causing an inflammatory response and an accumulation of neutrophils and macrophages in the area. Several weeks or months may pass before an immunological response is mounted by T cells and B cells. Eventually, the lesions in the alveoli become walled off, forming small round lesions called tubercles
. Bacteria continue to be released into the center of the tubercles and the chronic immune response results in tissue damage and induction of apoptosis (programmed host-cell death) in a process called liquefaction. This creates a caseous center, or air pocket, where the aerobic M. tuberculosis
can grow and multiply. Tubercles may eventually rupture and bacterial cells can invade pulmonary capillaries; from there, bacteria can spread through the bloodstream to other organs, a condition known as miliary tuberculosis
. The rupture of tubercles also facilitates transmission of the bacteria to other individuals via droplet aerosols that exit the body in coughs. Because these droplets can be very small and stay aloft for a long time, special precautions are necessary when caring for patients with TB, such as the use of face masks and negative-pressure ventilation and filtering systems.
Eventually, most lesions heal to form calcified Ghon complexes
. These structures are visible on chest radiographs and are a useful diagnostic feature. But even after the disease has apparently ended, viable bacteria remain sequestered in these locations. Release of these organisms at a later time can produce reactivation tuberculosis
(or secondary TB). This is mainly observed in people with alcoholism, the elderly, or in otherwise immunocompromised individuals (Figure 9).
Figure 9. Click for a larger image. In the infectious cycle of tuberculosis, the immune response of most infected individuals (approximately 90%) results in the formation of tubercles in which the infection is walled off. The remainder will suffer progressive primary tuberculosis. The sequestered bacteria may be reactivated to form secondary tuberculosis in immunocompromised patients at a later time. (credit: modification of work by Centers for Disease Control and Prevention)
Because TB is a chronic disease, chemotherapeutic treatments often continue for months or years. Multidrug resistant (MDR-TB) and extensively drug-resistant (XDR-TB) strains of M. tuberculosis
are a growing clinical concern. These strains can arise due to misuse or mismanagement of antibiotic therapies. Therefore, it is imperative that proper multidrug protocols are used to treat these infections. Common antibiotics included in these mixtures are isoniazid, rifampin, ethambutol, and pyrazinamide.
A TB vaccine is available that is based on the so-called bacillus Calmette-Guérin (BCG) strain of M. bovis
commonly found in cattle. In the United States, the BCG vaccine
is only given to health-care workers and members of the military who are at risk of exposure to active cases of TB. It is used more broadly worldwide. Many individuals born in other countries have been vaccinated with BCG strain. BCG is used in many countries with a high prevalence of TB, to prevent childhood tuberculous meningitis and miliary disease.
The Mantoux tuberculin skin test
(Figure 10) is regularly used in the United States to screen for potential TB exposure (see Hypersensitivities
). However, prior vaccinations with the BCG vaccine can cause false-positive results. Chest radiographs to detect Ghon complex formation are required, therefore, to confirm exposure.
Figure 10. (a) The Mantoux skin test for tuberculosis involves injecting the subject with tuberculin protein derivative. The injection should initially produce a raised wheal. (b) The test should be read in 48–72 hours. A positive result is indicated by redness, swelling, or hardness; the size of the responding region is measured to determine the final result. (credit a, b: modification of work by Centers for Disease Control and Prevention)
Think about It
- What characteristic of Mycobacterium tuberculosis allows it to evade the immune response?
- What happens to cause miliary tuberculosis?
- Explain the limitations of the Mantoux tuberculin skin test.
Pertussis (Whooping Cough)
The causative agent of pertussis
, commonly called whooping cough
, is Bordetella pertussis
, a gram-negative coccobacillus. The disease is characterized by mucus accumulation in the lungs that leads to a long period of severe coughing. Sometimes, following a bout of coughing, a sound resembling a "whoop" is produced as air is inhaled through the inflamed and restricted airway—hence the name whooping cough. Although adults can be infected, the symptoms of this disease are most pronounced in infants and children. Pertussis is highly communicable through droplet transmission, so the uncontrollable coughing produced is an efficient means of transmitting the disease in a susceptible population.
Following inhalation, B. pertussis
specifically attaches to epithelial cells using an adhesin
, filamentous hemagglutinin. The bacteria then grow at the site of infection and cause disease symptoms through the production of exotoxins. One of the main virulence factors of this organism is an A-B exotoxin
called the pertussis toxin (PT)
. When PT enters the host cells, it increases the cyclic adenosine monophosphate (cAMP) levels and disrupts cellular signaling. PT is known to enhance inflammatory responses involving histamine and serotonin. In addition to PT, B. pertussis
produces a tracheal cytotoxin that damages ciliated epithelial cells and results in accumulation of mucus in the lungs. The mucus can support the colonization and growth of other microbes and, as a consequence, secondary infections are common. Together, the effects of these factors produce the cough that characterizes this infection.
A pertussis infection can be divided into three distinct stages. The initial infection, termed the catarrhal stage
, is relatively mild and unremarkable. The signs and symptoms may include nasal congestion, a runny nose, sneezing, and a low-grade fever. This, however, is the stage in which B. pertussis
is most infectious. In the paroxysmal stage
, mucus accumulation leads to uncontrollable coughing spasms that can last for several minutes and frequently induce vomiting. The paroxysmal stage can last for several weeks. A long convalescence stage
follows the paroxysmal stage, during which time patients experience a chronic cough that can last for up to several months. In fact, the disease is sometimes called the 100-day cough.
In infants, coughing can be forceful enough to cause fractures to the ribs, and prolonged infections can lead to death. The CDC reported 20 pertussis-related deaths in 2012, but that number had declined to five by 2015.
During the first 2 weeks of infection, laboratory diagnosis is best performed by culturing the organism directly from a nasopharyngeal (NP) specimen collected from the posterior nasopharynx. The NP specimen is streaked onto Bordet-Gengou medium
. The specimens must be transported to the laboratory as quickly as possible, even if transport media are used. Transport times of longer than 24 hours reduce the viability of B. pertussis
Within the first month of infection, B. pertussis
can be diagnosed using PCR techniques. During the later stages of infection, pertussis-specific antibodies can be immunologically detected using an enzyme-linked immunosorbent assay (ELISA).
Pertussis is generally a self-limiting disease. Antibiotic therapy with erythromycin or tetracycline is only effective at the very earliest stages of disease. Antibiotics given later in the infection, and prophylactically to uninfected individuals, reduce the rate of transmission. Active vaccination is a better approach to control this disease. The DPT vaccine
was once in common use in the United States. In that vaccine, the P component consisted of killed whole-cell B. pertussis
preparations. Because of some adverse effects, that preparation has now been superseded by the DTaP
and Tdap vaccine
s. In both of these new vaccines, the "aP" component is a pertussis toxoid.
Widespread vaccination has greatly reduced the number of reported cases and prevented large epidemics of pertussis. Recently, however, pertussis has begun to reemerge as a childhood disease in some states because of declining vaccination rates and an increasing population of susceptible children.
Think about It
- What accounts for the mucus production in a pertussis infection?
- What are the signs and symptoms associated with the three stages of pertussis?
- Why is pertussis becoming more common in the United States?
An atypical pneumonia called Legionnaires disease
(also known as legionellosis) is caused by an aerobic gram-negative bacillus, Legionella pneumophila
. This bacterium infects free-living amoebae that inhabit moist environments, and infections typically occur from human-made reservoirs such as air-conditioning cooling towers, humidifiers, misting systems, and fountains. Aerosols from these reservoirs can lead to infections of susceptible individuals, especially those suffering from chronic heart or lung disease or other conditions that weaken the immune system.
When L. pneumophila
bacteria enter the alveoli, they are phagocytized by resident macrophages. However, L. pneumophila
uses a secretion system to insert proteins in the endosomal membrane of the macrophage; these proteins prevent lysosomal fusion, allowing L. pneumophila
to continue to proliferate within the phagosome. The resulting respiratory disease can range from mild to severe pneumonia, depending on the status of the host’s immune defenses. Although this disease primarily affects the lungs, it can also cause fever, nausea, vomiting, confusion, and other neurological effects.
Diagnosis of Legionnaires disease is somewhat complicated. L. pneumophila
is a fastidious bacterium and is difficult to culture. In addition, since the bacterial cells are not efficiently stained with the Gram stain, other staining techniques, such as the Warthin-Starry silver-precipitate procedure
, must be used to visualize this pathogen. A rapid diagnostic test has been developed that detects the presence of Legionella
antigen in a patient’s urine; results take less than 1 hour, and the test has high selectivity and specificity (greater than 90%). Unfortunately, the test only works for one serotype of L. pneumophila
(type 1, the serotype responsible for most infections). Consequently, isolation and identification of L. pneumophila
from sputum remains the defining test for diagnosis.
Once diagnosed, Legionnaire disease can be effectively treated with fluoroquinolone and macrolide antibiotics. However, the disease is sometimes fatal; about 10% of patients die of complications. There is currently no vaccine available.
Think about It
- Why is Legionnaires disease associated with air-conditioning systems?
- How does Legionella pneumophila circumvent the immune system?
The zoonotic disease Q fever
is caused by a rickettsia, Coxiella burnetii
. The primary reservoirs for this bacterium are domesticated livestock such as cattle, sheep, and goats. The bacterium may be transmitted by ticks or through exposure to the urine, feces, milk, or amniotic fluid of an infected animal. In humans, the primary route of infection is through inhalation of contaminated farmyard aerosols. It is, therefore, largely an occupational disease of farmers. Humans are acutely sensitive to C. burnetii
—the infective dose is estimated to be just a few cells. In addition, the organism is hardy and can survive in a dry environment for an extended time. Symptoms associated with acute Q fever include high fever, headache, coughing, pneumonia, and general malaise. In a small number of patients (less than 5%), the condition may become chronic, often leading to endocarditis, which may be fatal.
Diagnosing rickettsial infection by cultivation in the laboratory is both difficult and hazardous because of the easy aerosolization of the bacteria, so PCR and ELISA are commonly used. Doxycycline is the first-line drug to treat acute Q fever. In chronic Q fever, doxycycline
is often paired with hydroxychloroquine
Bacterial Diseases of the Respiratory Tract
Numerous pathogens can cause infections of the respiratory tract. Many of these infections produce similar signs and symptoms, but appropriate treatment depends on accurate diagnosis through laboratory testing. The tables in Table 1 and Table 2 summarize the most important bacterial respiratory infections, with the latter focusing specifically on forms of bacterial pneumonia.
|Table 1. Bacterial Infections of the Respiratory Tract
||Signs and Symptoms
|Acute otitis media (AOM)
||Haemophilus influenzae, Streptococcus pneumoniae, Moraxella catarrhalis, others
||Earache, possible effusion; may cause fever, nausea, vomiting, diarrhea
||Often a secondary infection; bacteria from respiratory tract become trapped in eustachian tube, cause infection
||Pseudomembrane on throat, possibly leading to suffocation and death
||Inhalation of respiratory droplets or aerosols from infected person
||Identification of bacteria in throat swabs; PCR to detect diphtheria toxin in vitro
||Erythromycin, penicillin, antitoxin produced in horses
||DtaP, Tdap, DT, Td, DTP
||Cough, fever, muscle aches, headaches, nausea, vomiting, confusion; sometimes fatal
||Inhalation of aerosols from contaminated water reservoirs
||Isolation, using Warthin-Starry procedure, of bacteria in sputum
|Pertussis (whooping cough)
||Severe coughing with “whoop” sound; chronic cough lasting several months; can be fatal in infants
||Inhalation of respiratory droplets from infected person
||Direct culture of throat swab, PCR, ELISA
||High fever, coughing, pneumonia, malaise; in chronic cases, potentially fatal endocarditis
||Inhalation of aerosols of urine, feces, milk, or amniotic fluid of infected cattle, sheep, goats
|Streptococcal pharyngitis, scarlet fever
||Fever, sore throat, inflammation of pharynx and tonsils, petechiae, swollen lymph nodes; skin rash (scarlet fever), strawberry tongue
||Direct contact, inhalation of respiratory droplets or aerosols from infected person
||Direct culture of throat swab, rapid enzyme immunoassay
||Formation of tubercles in lungs; rupture of tubercles, leading to chronic, bloody cough; healed tubercles (Ghon complexes) visible in radiographs; can be fatal
||Inhalation of respiratory droplets or aerosols from infected person
||Mantoux tuberculin skin test with chest radiograph to identify Ghon complexes
||Isoniazid, rifampin, ethambutol, pyrazinamide
|Table 2. Bacterial Causes of Pneumonia
||Signs and Symptoms
||Chlamydophila pneumoniae, C. psittaci, Chlamydia trachomatis
||Bronchitis; mild to severe respiratory distress
||Inhalation of respiratory droplets or aerosols from infected person (C. pneumoniae); exposure to infected bird (C. psittaci); exposure in the birth canal (Chlamydia trachomatis)
||Tissue culture, PCR
||Cough, fever or low body temperature, chills, chest pain, headache, fatigue
||Inhalation of respiratory droplets or aerosols from infected person or asymptomatic carrier
||Culture on chocolate agar, serotyping of blood or cerebrospinal fluid samples
||Klebsiella pneumoniae, others
||Lung necrosis, “currant jelly” sputum; often fatal
||Health care associated; bacteria introduced via contaminated ventilators, intubation, or other medical equipment
||Multidrug resistant; antibiotic susceptibility testing necessary
|Mycoplasma pneumonia (walking pneumonia)
||Low fever, persistent cough
||Inhalation of respiratory droplets or aerosols from infected person
||Culture with penicillin, thallium acetate
||Productive cough, bloody sputum, fever, chills, chest pain, respiratory distress
||Direct contact with respiratory secretions
||Gram stain, blood agar culture with optichin and sodium deoxycholate, quellung reaction
||β-lactams, macrolides or cephalosporin, fluoroquinolones
||Pneumococcal conjugate vaccine (PCV13), pneumococcal polysaccharide vaccine (PPSV23)
||Viscous fluid and chronic inflammation of lungs; often fatal
||Health care associated; bacteria introduced via contaminated ventilators; also frequently affects patients with cystic fibrosis
||Culture from sputum or other body fluid
||Multidrug resistant; antibiotic susceptibility testing necessary
Key Concepts and Summary
- A wide variety of bacteria can cause respiratory diseases; most are treatable with antibiotics or preventable with vaccines.
- Streptococcus pyogenes causes strep throat, an infection of the pharynx that also causes high fever and can lead to scarlet fever, acute rheumatic fever, and acute glomerulonephritis.
- Acute otitis media is an infection of the middle ear that may be caused by several bacteria, including Streptococcus pneumoniae, Haemophilus influenzae, and Moraxella catarrhalis. The infection can block the eustachian tubes, leading to otitis media with effusion.
- Diphtheria, caused by Corynebacterium diphtheriae, is now a rare disease because of widespread vaccination. The bacteria produce exotoxins that kill cells in the pharynx, leading to the formation of a pseudomembrane; and damage other parts of the body.
- Bacterial pneumonia results from infections that cause inflammation and fluid accumulation in the alveoli. It is most commonly caused by S. pneumoniae or H. influenzae. The former is commonly multidrug resistant.
- Mycoplasma pneumonia results from infection by Mycoplasma pneumoniae; it can spread quickly, but the disease is mild and self-limiting.
- Chlamydial pneumonia can be caused by three pathogens that are obligate intracellular parasites. Chlamydophila pneumoniae is typically transmitted from an infected person, whereas C. psittaci is typically transmitted from an infected bird. Chlamydia trachomatis, may cause pneumonia in infants.
- Several other bacteria can cause pneumonia in immunocompromised individuals and those with cystic fibrosis.
- Tuberculosis is caused by Mycobacterium tuberculosis. Infection leads to the production of protective tubercles in the alveoli and calcified Ghon complexes that can harbor the bacteria for a long time. Antibiotic-resistant forms are common and treatment is typically long term.
- Pertussis is caused by Bordetella pertussis. Mucus accumulation in the lungs leads to prolonged severe coughing episodes (whooping cough) that facilitate transmission. Despite an available vaccine, outbreaks are still common.
- Legionnaires disease is caused by infection from environmental reservoirs of the Legionella pneumophila bacterium. The bacterium is endocytic within macrophages and infection can lead to pneumonia, particularly among immunocompromised individuals.
- Q fever is caused by Coxiella burnetii, whose primary hosts are domesticated mammals (zoonotic disease). It causes pneumonia primarily in farm workers and can lead to serious complications, such as endocarditis.
Which of the following does not involve a bacterial exotoxin?
- whooping cough
- scarlet fever
- Q fever
What disease is caused by Coxiella burnetii
- Q fever
- walking pneumonia
In which stage of pertussis is the characteristic whooping sound made?
What is the causative agent of Q fever?
- Coxiella burnetii
- Chlamydophila psittaci
- Mycoplasma pneumoniae
- Streptococcus pyogenes
Which of these microbes causes "walking pneumonia"?
- Klebsiella pneumoniae
- Streptococcus pneumoniae
- Mycoplasma pneumoniae
- Chlamydophila pneumoniae
Fill in the Blank
Calcified lesions called __________ form in the lungs of patients with TB.
An inflammation of the middle ear is called __________.
The __________ is used to serologically identify Streptococcus pneumoniae
__________ is a zoonotic infection that can be contracted by people who handle birds.
The main virulence factor involved in scarlet fever is the __________.
Think about It
- Name three bacteria that commonly cause pneumonia. Which is the most common cause?
- How does smoking make an individual more susceptible to infections?
- How does the diphtheria pathogen form a pseudomembrane?
- Why might β-lactam antibiotics be ineffective against Mycoplasma pneumoniae infections?
- Why is proper antibiotic therapy especially important for patients with tuberculosis?
Licenses and Attributions
